Products
Digital Water Level Indicator (SMC-DI)
SMC-DI is 5 levels indicator device with Digital Seven Segment Display. It gives unique musical alarms at LOW and FULL levels with an option to select alarm volume and time along with many features listed below. It uses DC adapter so there is no worry of electric shock, unlike products wherein 220V AC is used for power them ON.
Features and Specifications:
Latest Microcontroller Technology and Pulse Sensing
Sensor cleaning not needed.
5 Water Levels Indication (1,2,3,4 and 5)
Unique Musical Alarms at LOW and FULL levels
Soft Alarm Reset and Alarm Auto Off timer
Alarm tone selection option
5VDC input supply
In the Box:
Indicator Device: 1 No, DC Adapter: 1 No, SS Contact Type sensors: 6 Nos, User Manual, Warranty Card
Water Level Indicator (SAN4)
It gives 4 levels of Indications (25%, 50%, 75% and FULL). It also gives continuous beep sound in case water level falls below 25% or goes above FULL level. It uses DC adapter as a power supply option, so there is no worry of electric shock, unlike products wherein 220V AC is used for power them ON.
Features and Specifications:
Sleek Body Design
4 Water Levels Indications (25% 50% 75% and FULL)
BEEP alarm at LOW and FULL levels
Alarm ON/OFF switch
5VDC/12VDC input supply
In the Box:
Indicator Device: 1 No, DC Adapter: 1 No, SS Contact Type sensors: 5 Nos, User Manual, Warranty Card
Water Level Indicator (SMC-I5)
SMC-I5 is 5 levels indicator device with LEDs display. It gives unique musical alarms at LOW and FULL levels with an option to select alarm volume and time along with many features listed below. It uses DC adapter so there is no worry of electric shock, unlike products wherein 220V AC is used for power them ON.
Features and Specifications:
Latest Microcontroller Technology and Pulse Sensing
Sensor cleaning not needed.
5 Water Levels Indication (20% 40% 60% 80% and FULL)
Unique Musical Alarms at LOW and FULL levels
Soft Alarm Reset and Alarm Auto Off Timer
Alarm Tone Selection Option
5VDC Input Supply
In the Box:
Indicator Device: 1 No, DC Adapter: 1 No, SS Contact Type sensors: 6 Nos, User Manual, Warranty Card
Dual Tank Water Level Indicator (SMC-DT)
SMC-DT is a Dual Tank Water Level indicator device. It shows 3 levels of both tanks (Green LEDs for Tank 1 & Red LEDs for Tank 2) and unique musical alarms at LOW and FULL levels for both the Tanks. It uses DC adapter so there is no worry of electric shock, unlike products wherein 220V AC is used for power them ON.
Features and Specifications:
Latest Microcontroller Technology and Pulse Sensing
Sensor cleaning not needed.
3 Water Levels for both Tanks (Reserve, Half FULL)
Unique Musical Alarms at LOW and FULL levels
Soft Alarm Reset and Alarm Auto Off Timer
Alarm Tone Selection Option
5VDC Input Supply
In the Box:
Indicator Device: 1 No, DC Adapter: 1 No, SS Contact Type sensors: 8 Nos, User Manual, Warranty Card
Automatic Water Level Controller (Model -WLS LT) is based on latest microcontroller technology with pulse sensing technique (sensor cleaning not required). It is primarily used for the automation of "Corporation Water Supply Automation.
This device uses unique 2 stage water detection (at input as well at tank). It switches on motor as water touches the input water detect sensor and also touches second water detect sensor at tank (at the mouth of pipe from where water is falling in tank). It makes sure that the motor should only continue to run if water is coming and falling in tank. It protects motor from false water detection (Incoming water pressure is low and water is touching input sensor bit not reaching at tank, or in case motor has taken air).
Features and specifications:
Latest Microcontroller Technology
Pulse Sensing (No salt deposition on sensors, sensors cleaning not needed)
Motor AUTO ON as corporation water comes.
Motor AUTO OFF as Tank gets FULL.
Motor AUTO OFF as water stops coming.
Motor Dry Run and Over Run Protection
Auto and Bypass (Manual) selection switch and Tank Top-up switch.
LED Indicators: Power ON, Motor ON, Water Level, Incoming Water.
15Amp Relay (for upto 1 HP Motor)
High Quality 316 Grade SS Contact Type Sensors
12 Months Warranty
220V AC Input and 220V AC Output for motor.
Package includes:
Automatic Water Level Controller Device: 1 No.
SS Contact Type Sensors: 3 Nos.
Water Detect Sensors: 2 Nos.
Manual/ Wiring Diagram
Warranty Card
